ERW Pipes & Tubes (Electric Resistance Welded)
ERW pipes and tubes are manufactured by feeding a rectangular steel strip through a rolling machine that gradually curls the long edges upward toward each other, forming a round (cylindrical) shape. In the ERW process, high-frequency electrical current is passed between the two edges, causing them to heat, melt, and fuse together — creating a longitudinal weld along the full length of the pipe.
A key advantage of ERW pipe is that no filler (fusion) metal is used, and the weld seam is typically smooth and uniform, often difficult to see or feel.
Modern High-Frequency ERW Technology
Welded pipe manufacturing has advanced significantly over the years. One of the most important improvements was the industry-wide shift to high-frequency electric current welding. Earlier low-frequency ERW weld seams (common prior to the 1970s) were generally more susceptible to corrosion and seam-related failures compared to modern high-frequency ERW.
In manufacturing ERW steel pipes and tubing, we use high-quality steel such as continuous-cast, fully-killed, control-rolled, fine-grain, low-carbon material — supporting consistent welding, performance, and reliability.
High-performance ERW pipes and tubes are known for:
- High strength
- Good corrosion resistance
- High deformability
- Strong toughness and durability
Applications
ERW steel pipes and tubes are widely used for:
- General engineering and fabrication
- Fencing
- Scaffolding
- Line pipe applications
- Structural and industrial use (based on specification)
Product Range & Capabilities
We offer ERW pipe and tubing in a broad range of sizes, shapes, and thicknesses:
ERW Pipe
- Lengths from single random up to 46 feet (depending on mill capability)
- Size ½”-6” in Schedule 10 & 40
ERW Tube / Hollow Sections
½”x ½” -6”x6” up to ¼” thickness
Square sizes : ½”x ½” -6”x6” up to ¼” thickness
- Rectangular: 1” x ½” – 6” x 2” up to  ¼"thickness
- Available in multiple quality levels and wall thickness combinations
Pre-Galvanized Pipe & Tube
- Pre-galvanized options available in a wide range of thicknesses and size combinations
Plates/ Sheets
12 Ga- ½” thick in 4’x8’ to 6’x10’
Based on customer requirements, we can manufacture ERW pipes and tubes in different sizes and shapes to meet project needs.
